Product introduction
Product Type: KCD1-12-BA1A-B-B-98
Max.Rating Current: 16(4)A 250V AC
Contact Resistance: ≤50mΩ
Insulation Resistance: ≥1000MΩ
Dielectric Strength: 1500V AC, 1min
Electronic Life: 10,000 cycles
Mechanical Life: 50,000 cycles
Operating Temperature: T55, T85, T125
Protection Degree: IP40
Certificate: CE、CQC、UL、CB、ENEC、ROHS
