KCD3 Rocker Switch

Home / Products / Electrical Accessories / Rocker Switch / KCD3 Rocker Switch / KCD3 SP-ST 2pins 250v white rocker switch

  • KCD3  SP-ST 2pins 250v white rocker switch

  • KCD3  SP-ST 2pins 250v white rocker switch

  • KCD3  SP-ST 2pins 250v white rocker switch

  • KCD3  SP-ST 2pins 250v white rocker switch

KCD3 SP-ST 2pins 250v white rocker switch

Name:KCD3  SP-ST 2pins 250v white rocker switch
Product Type: KCD3-11-CB1B-W-W-01
Max.Rating Current: 10A 250V AC
Contact Resistance: ≤50mΩ
Insulation Resistance:  ≥1,000MΩ
Dielectric Strength: 1,500VAC 1min
Electronic Life: 10,000 cycles
Mechanical Life: 50,000 cycles
Operating Temperature:T55,T105
Protection Degree: IP40
Certificate: UL、CE、CQC、CB、ENEC、ROHS

Product introduction

KCD3  SP-ST 2pins 250v white rocker switch

KCD3  SP-ST 2pins 250v white rocker switch

KCD3  SP-ST 2pins 250v white rocker switch
