KCD3 Rocker Switch

Home / Products / Electrical Accessories / Rocker Switch / KCD3 Rocker Switch / KCD3 UL CE T85 55 250V AC 2 Pin Black Plastic Mini Rocker Switch

  • KCD3 UL CE T85 55 250V AC 2 Pin Black Plastic Mini Rocker Switch

  • KCD3 UL CE T85 55 250V AC 2 Pin Black Plastic Mini Rocker Switch

  • KCD3 UL CE T85 55 250V AC 2 Pin Black Plastic Mini Rocker Switch

KCD3 UL CE T85 55 250V AC 2 Pin Black Plastic Mini Rocker Switch

Name:KCD3 UL CE T85 55 250V AC 2 Pin Black Plastic Mini Rocker Switch
Product Type:  KCD3-11-CB1K-B-B-01
Max.Rating Current: 10A 250V AC
Contact Resistance: ≤50mΩ
Insulation Resistance: ≥1,000MΩ
Dielectric Strength: 1,500VAC 1min
Electronic Life: 10,000 cycles
Mechanical Life: 50,000 cycles
Operating Temperature:T55,T105
Protection Degree: IP40
Certificate: UL、CE、CQC、CB、ENEC、ROHS

Product introduction

KCD3 UL CE T85 55 250V AC 2 Pin Black Plastic Mini Rocker Switch

KCD3 UL CE T85 55 250V AC 2 Pin Black Plastic Mini Rocker Switch

KCD3 UL CE T85 55 250V AC 2 Pin Black Plastic Mini Rocker Switch
