Home / Products / Electrical Accessories / Rocker Switch / KCD5 Rocker Switch / Hot sale red 6a 250v t120 kcd5 on off on illuminated rocker switch
Product introduction
Product Type: KCD5-12-CA1B-B-R-01
Max.Rating Current: 6A 250V AC
Contact Resistance: ≤50mΩ
Insulation Resistance: ≥1000MΩ
Dielectric Strength: 1500V AC, 1min
Electronic Life: 10,000 cycles
Mechanical Life: 50,000 cycles
Operating Temperature: T55
Protection Degree: IP40
Certificate: CE, CQC, UL
